Instrument cluster

Figure 1. Type A
OMQ4A035147
Figure 2. Type B
OMQ4A035144

The actual instrument cluster in the vehicle may differ from the illustrations.

  1. Warning and indicator lights

  2. Speedometer

  3. Tachometer

  4. Distance to empty

  5. Fuel gauge

  6. Outside temperature gauge

  7. Transmission shift indicator

  8. Engine coolant temperature gauge

  9. Odometer
