Replacing luggage lamp bulb (Bulb type)

Replacing luggage lamp bulb (Bulb type)

Using a flat-blade screwdriver, gently pry the lens cover from lamp housing.
Remove the bulb by pulling it straight out.
Install a new bulb in the socket.
Align the lens cover tabs with the lamp housing notches and snap the lens into place.

Fuel requirements

Vehicle modifications

Vehicle break-in process

Risk of fire or burns when parking or stopping vehicle

Vehicle handling instructions

Vehicle data collection and Event Data Recorders

Your vehicle at a glance

Exterior overview

Interior overview

Instrument panel overview

Engine compartment

Safety features of your vehicle

Important safety precautions

Child Restraint System (CRS)

Air bag - advanced Supplemental Restraint System

Features of your vehicle

Digital Key 2 Touch

Theft-alarm system

Driver position memory system for power seat

Manual liftgate

Smart Power Liftgate

Fuel filler door

Dual Wide Sunroof

Instrument cluster

Warning and indicator lights

Vehicle settings (infotainment system)

Head-Up Display (HUD)

Wipers and washers

Interior lights

Climate control system

Manual climate control system

Automatic climate control system

Windshield defrosting and defogging

Additional features of climate control

Storage compartment

Interior features

Exterior features

Declaration of Conformity

Driving your vehicle

Be sure the exhaust system does not leak.

ENGINE START/STOP button

Automatic transmission

All Wheel Drive (AWD) system

Idle Stop and Go (ISG) system

Drive mode integrated control system (FWD)

Drive mode integrated control system (AWD)

Economical operation

Special driving conditions

Vehicle load limit

Driver assistance system

Forward Collision-Avoidance Assist (FCA) (Sensor Fusion)

Lane Keeping Assist (LKA)

Blind-Spot Collision-Avoidance Warning (BCW)

Safe Exit Assist (SEA)

Manual Speed Limit Assist (MSLA)

Intelligent Speed Limit Assist (ISLA)

Driver Attention Warning (DAW)

Blind-Spot View Monitor (BVM)

Smart Cruise Control (SCC)

Navigation-based Smart Cruise Control (NSCC)

Lane Following Assist (LFA)

Highway Driving Assist (HDA)

Rear View Monitor (RVM)

Surround View Monitor (SVM)

Rear Cross-Traffic Collision-Avoidance Assist (RCCA)

Reverse Parking Distance Warning (PDW)

Forward/Reverse Parking Distance Warning (PDW)

Reverse Parking Collision-Avoidance Assist (PCA)

Declaration of conformity

What to do in an emergency

In case of an emergency while driving

If the engine will not start

Emergency starting

If the engine overheats

Tire Pressure Monitoring System (TPMS)

If you have a flat tire (with spare tire)

Engine compartment

Maintenance services

Owner maintenance

Scheduled maintenance service

Explanation of scheduled maintenance items

Engine oil and filter

Air cleaner filter

Climate control air filter

Tires and wheels

Appearance care

Emission control system

California perchlorate notice

Specifications, Consumer information and Reporting safety defects

Gross Vehicle Weight

Air conditioning system

Tires and wheels

Recommended lubricants and capacities

Vehicle Idenjpgication Number (VIN)

Vehicle cerjpgication

Tire specification and pressure label

Refrigerant label

Consumer Assistance (U.S. only)

Electrical Equipment (U.S. only)

Reporting Safety Defects (U.S. only)

Online factory authorized manuals (U.S. only)

Maintenance
- Engine compartment
  Open the hood to see the engine compartment.
- Maintenance services
  You should exercise the utmost care to prevent damage to your vehicle and injury to yourself whenever performing any maintenance or inspection procedures.
- Owner maintenance
- Scheduled maintenance service
  Follow the Normal Maintenance Schedule if the vehicle is usually operated where none of the following conditions apply.
- Explanation of scheduled maintenance items
  The following parts require scheduled maintenance.
- Engine oil and filter
- Engine coolant
- Brake fluid
  The brake fluid acts to transmit force to the brake when the driver depresses the brake pedal. Brake fluid must be maintained periodically to ensure that the brakes operate smoothly.
- Washer fluid
  Washer fluid is used when wiping the windshield of the vehicle with a windshield wiper. You should check and refill washer fluid periodically to make sure that it doesn't run out.
- Air cleaner filter
  A Genuine Kia air cleaner filter is recommended when the filter is replaced.
- Climate control air filter
  The climate control air filter should be replaced according to the maintenance schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier.
- Wiper blades
  When the wipers no longer clean adequately, the blades may be worn or cracked, and require replacement.
- Battery
  The battery powers the engine in order to move the vehicle as well as supplying power to the various devices installed in the vehicle.
- Tires and wheels
  For proper maintenance, safety, and maximum fuel economy, you must always maintain the recommended tire inflation pressures and stay within the load limits and weight distribution recommended for your vehicle.
- Fuses
  A vehicle's electrical system is protected from electrical overload damage by fuses.
- Light bulbs
  Light bulbs are installed in various parts of the vehicle to provide lighting inside and outside the vehicle as well as to alert other vehicles.
  - Replacing lights (LED type)
  - Replacing front fog lamp (LED type)
    If the front fog lamp (1) does not operate, have the vehicle checked by an authorized Kia dealer.
  - Replacing stop lamp, tail lamp, and rear turn signal lamp (Bulb type) (Rear combination lamp Type A)
  - Replacing back up lamp (Bulb type) (Rear combination lamp Type A)
  - Replacing high mounted stop lamp (LED type)
    If the High Mounted Stop Lamp (LED) (1), does not operate, have the vehicle checked by an authorized Kia dealer.
  - Replacing license plate lamp (Bulb type)
  - Replacing map lamp (Bulb type)
  - Replacing vanity mirror lamp bulb (Bulb type)
  - Replacing room lamp (bulb type) bulb
  - Replacing glove box lamp (Bulb type)
  - Replacing luggage lamp bulb (Bulb type)
- Appearance care
  Use the information in the following sections to keep the exterior and interior of your vehicle clean.
- Emission control system
  The emission control system of your vehicle is covered by a written limited warranty. Please see the warranty information contained in the Warranty & Consumer Information manual in your vehicle.
- California perchlorate notice
