Full flat seats: (if equipped)

OKA4H023043

Only use the full flat seat mode when the 4th row seats are completely folded down.

  1. Push the 3rd row seats (1) toward the rear end of the vehicle as far as possible.

  2. Push the 2nd row seats (2) to the front of the vehicle as far as possible.

  3. Remove the 2nd row seat headrests (3).

  4. Fully recline the 2nd row seatbacks (4).

Pull up the seatback adjustment lever located on top of the 2nd, 3rd row centre seats to recline.

WARNING

  • Do not move the vehicle with a passenger and any full flat seat.

  • Make sure any part of the body, such as hand and foot, is well out-of-the way whilst adjusting the seatback recline angle.

NOTE

  • When returning the seats to upright positions, reinstall the headrests to original positions.

  • Do not put heavy pressure nor load heavy cargo on the seatback when in full flat position. It may damage the seatback.

  • Be careful of seat belt entanglement in fully flat mode. Protect against possible seat belt damage by storing it in seat belt holders.
