Ergo-motion seat modes

Comfort stretching

The seat can be moved to relieve the driver's pelvis and back fatigue.

OMV023010

Operation

  • Each time the comfort stretch control switch located on the driver's door is pressed, the mode changes in the following order and is displayed on the infotainment system screen.

    • Pelvic: The cushion part moves to help the pelvis move left and right.

    • Lumbar: The lumbar support moves and helps exercise the back and front of the waist.

    • Whole Body: The cushion and lumbar support move sequentially to help the whole body exercise to relieve fatigue.

    • Off: Disable the comfort stretching function.

  • Comfort Stretching can be turned off by pressing the switch for approximately 1 second or longer during comfort stretching operation.

  • During the operation of the Comfort Stretching function, press any of the seat adjustment switches (cushion support, lumbar support, bolster adjustment device), so the operation stops.

  • Select Setup → Vehicle → Seat → Ergo-Motion Seat → Comfortable Stretch from the infotainment system to change the intensity and duration of the comfort stretching feature.

    • Intensity: Normal/ Strong

    • Duration: Short (10 min.), Normal (15 min.), Long (20 min.)

Posture assist

After about an hour of driving with the driver's seat belt fastened, the posture assist function automatically turns on and assists the driver's posture by adjusting the driver's seat's hips and waist parts.

Operation

  • Select Setup → Vehicle → Seat → Ergo-Motion Seat → Smart Posture Assist from the infotainment system.

  • If you press the seat adjustment switch (cushion support, lumbar support, bolster adjustment device) while the posture assist function is operating, the operation stops.

Operating condition(s)

If both conditions below are satisfied, the posture assist function automatically operates to assist the driver's posture.

  • The vehicle is in ON position

  • The driver's side seatbelt is fastened

Lumbar Stabilization System while driving

This function repeats the adjustment of the lumbar support in a regular pattern to reduce back fatigue when driving continuously for a long time.

Operation

  • Select Setup → Vehicle → Seat → Ergo-Motion Seat → Use Lumbar Stabilization System while Driving (Off, 30 min, 1hour) from the infotainment system.

  • If you press the lumbar support adjustment switch while the lumber support function is operating while driving, the operation stops.

Operating condition(s)

Activates automatically after 30 minutes or 1 hour of continuous driving.
