Replacing lights (LED type)

If the LED lamp is not functioning, have your vehicle inspected by a professional workshop. Kia recommends visiting an authorized Kia dealer or service partner. The LED lamp cannot be replaced as an individual component since it is an integrated unit. Instead, the entire LED lamp unit must be replaced.

A skilled technician should check or repair the LED lamp, for it may damage related parts of the vehicle.

CAUTION

If the high-mounted stop lamp (LED) is not functioning, have your vehicle inspected by a professional workshop. Kia recommends visiting an authorized Kia dealer or service partner. The LED lamp cannot be replaced as a single unit because it is an integrated component. Instead, the entire LED lamp unit must be replaced. It’s essential to have a skilled technician check or repair the high-mounted stop lamp (LED) to prevent any damage to related vehicle parts.

Replacing day time running lamp/position Lamp/front turn signal lamp, headlamp (high/low) (LED type)

If day time running lamp/position lamp/front turn signal lamp, headlamp (high/low) are not functioning, have your vehicle inspected by a professional workshop. Kia recommends visiting an authorized Kia dealer or service partner.

N_QVe27_B12_031_E

  1. Headlamp (Low) (LED type)

  2. Headlamp (High) (LED type)

  3. Front turn signal lamp (LED type)

  4. Day time running light/Position lamp (LED type)
NOTE

After replacing the headlamp assembly, have the headlamp aiming adjusted by a professional workshop. Kia recommends visiting an authorized Kia dealer or service partner.

Replacing side repeater lamp (LED type)

If side repeater lamp is not functioning, have your vehicle inspected by a professional workshop. Kia recommends visiting an authorized Kia dealer or service partner.

N_QVe27_B12_032_E

  1. Side repeater lamp (LED type)

Replacing tail lamp/stop lamp, reversing lamp, high mounted stop lamp, license plate lamp, rear fog lamp (LED type)

If tail lamp/stop lamp, reversing lamp, high mounted stop lamp, license plate lamp, rear fog lamp are not functioning, have your vehicle inspected by a professional workshop. Kia recommends visiting an authorized Kia dealer or service partner.

Figure 1. Rear combination lamp (Type A)
N_QVe27_B12_033_E
Figure 2. Rear combination lamp (Type B)
N_QVe27_C12_037_E
Figure 3. License plate lamp
N_QVe27_B12_035_E

  1. High mounted stop lamp (LED type)

  2. Tail lamp/Stop lamp (LED type)

  3. Rear turn signal lamp (LED type)

  4. Reversing lamp (LED type) (For LHD)

    Rear fog lamp (LED type) (For RHD)

  5. Reversing lamp (LED type) (For RHD)

    Rear fog lamp (LED type) (For LHD)

  6. License plate lamp (LED type)

Replacing interior lights (LED type)

If map lamp, room lamp, vanity mirror lamp, luggage lamp, glove box lamp, ambient light are not functioning, have your vehicle inspected by a professional workshop. Kia recommends visiting an authorized Kia dealer or service partner.

Figure 4. Map lamp
N_QVe27_B12_035_1_E
Figure 5. Room lamp
N_QVe27_B12_036_1_E
Figure 6. Glove box lamp
N_QVe27_C08_008_1_E
Figure 7. Vanity mirror lamp
N_QVe27_C08_007_1_E
Figure 8. Luggage lamp
N_QVe27_C08_006_1_E
Figure 9. Ambient light (if equipped)
N_QVe27_C08_009
