Checking the coolant level
WARNING
Removing radiator cap
Never attempt to remove the radiator cap while the engine is operating or hot. Doing so might lead to cooling system damage and could result in serious personal injury from escaping hot coolant or steam.
1
Turn the vehicle off and wait until it cools down.
2
Use extreme care when removing the radiator cap. Wrap a thick towel around it, and turn it counterclockwise slowly to the
first stop.
3
Step back while the pressure is released from the cooling system.
4
When you are sure all the pressure has been released, press down on the cap, using a thick towel, and continue turning counterclockwise
to remove it.
WARNING
Cooling fan
5
Check the condition and connections of all cooling system hoses and heater hoses.
6
Replace any swollen or deteriorated hoses.
7
Check the coolant level. The coolant level should be filled between F and L marks on the side of the coolant reservoir when
the engine room is cool.
8
If the coolant level is low, add enough specified coolant to provide protection against freezing and corrosion. Bring the
level to F, but do not overfill.
If frequent additions are required, see an authorized Kia dealer for a cooling system inspection.
