Instrument cluster

OCVGT034103N

1. Speedometer

  • MPH, km/h

  • The speed of the vehicle in kilometers per hour (km/h) or miles per hour (mph).

2. Distance to empty

  • Estimated distance the vehicle can be driven with the remaining electric energy.

3. Power/Charge gauge

  • The energy consumption rate of the vehicle and the charge/discharge status of the regenerative brakes.

4. Battery SOC (State of Charge) gauge

  • Charging status of the high voltage battery.

5. LCD display

For more information, refer to LCD display.

6. Warning and indicator lights

For more information, refer to Warning and indicator lights.

7. Gear shift indicator

  • The indicator displays which gear is selected.

8. Odometer

  • The odometer indicates the total distance that the vehicle has been driven.

9. Regenerative braking level indicator

NOTE

  • The information is displayed after getting information from a weather information provider via GPS. Depending on conditions of GPS reception, the information may be different from the current weather in your area.

  • Be careful while driving as dynamic-themed animation effects can distract the driver and lead to unexpected accidents.

NOTE

  • When the remaining battery is lower than 10% for the high voltage battery, the vehicle speed is limited and then eventually the vehicle will turn off. Charge the vehicle immediately.

  • If the vehicle is not on level ground or the battery power has been interrupted, the distance to empty function may not operate correctly.

  • The distance to empty may differ from the actual driving distance as it is an estimate of remaining driving distance.

  • The distance to empty may vary significantly based on driving conditions, driving habit, and condition of the vehicle.

  • Use a clean soft microfiber cloth to gently wipe any fingerprints off the touch screen.
