Master warning mode

Figure 1. Type B
OJA040513L
Figure 2. Type C
OJA040486

This warning light informs the driver the following situations.

  • Forward Collision-Avoidance Assist malfunction (if equipped)

  • Forward Collision-Avoidance Assist radar blocked (if equipped)

  • Blind-Spot Collision Warning malfunction (if equipped)

  • Blind-Spot Collision Warning radar blocked (if equipped)

  • TPMS failure, low pressure (if equipped), etc.

At this time, a Master Warning icon ( ) will appear on the LCD display. If the warning situation is solved, the master warning light will be turned off and the Master Warning icon will disappear.
