Center Door Lock/Unlock Relay

Power Window Main Switch, Passenger Power Window Switch

Power Window Main Switch

Rear Seat Warmer Control Module

Front Air Ventilation Seat Control Module, Front Seat Warmer Control Module

Passenger Power Seat Switch, Passenger Seat Relay Unit

Sunroof Controller (Blind Motor)

SRS (Supplemental Restraint System) Control Module

Sunroof Controller (Glass Motor)

Driver Power Seat Switch, Driver IMS (Integrated memory system) Control Module

Driver IMS (Integrated memory system) Control Module, Driver/Passenger Smart Key Outside Handle, Rain Sensor, Hazard Switch, Data Link Connector, Power Liftgate Unit

AMP (Amplifier)

BDC (Body Domain Controller), Ignition Switch, Auto Transmission Lever

Outside Mirror Folding/Unfolding Relay, Driver/Passenger Power Outside Mirror, Instrument Cluster, Air Conditioner Controller (LCD), Air Conditioner Control Module, Mood Lamp Unit, Console Mood Lamp, Mood Lamp (Passenger), Crash Pad Switch, Integrated Parking Assist Unit, Low Voltage DC-DC converter (450W)

Tailgate Relay

BDC (Body Domain Controller)

Stop Lamp Switch, BDC (Body Domain Controller)

Audio (Display), Audio/Video & Navigation Head Unit, Low Voltage DC-DC converter (200W)

Multifunction Switch

Front Air Ventilation Seat Control Module, Front/Rear Seat Warmer Control Module, E/R Junction Block (Windshield Heated Relay LH)

SRS (Supplemental Restraint System) Control Module

E/R Junction Block (PTC Heater Relay #1, Blower Relay), Air Conditioner Controller (LCD), Air Conditioner Control Module

Front USB Charger Connector, Driver/Passenger Seat USB Port

Console Switch, Drive Mode Switch, Data Link Connector, Auto Transmission Shift Lever Indicator

Intergrated Parking Assist Unit, BDC (Body Domain Controller), Audio Keyboard, Audio/Video & Navigation Keyboard, Power Outside Mirror Switch, AMP (Amplifier), Audio (Display), Audio/Video & Navigation Head Unit, Low Voltage DC-DC converter

BDC (Body Domain Controller)

Driver IMS (Integrated memory system) Control Module, Rear Seat Warmer Control Module, Front Air Ventilation Seat Control Module, AMP (Amplifier), Front Seat Warmer Control Module, Audio (Display), Audio/Video & Navigation Head Unit, Front Wireless Charger, Air Conditioner Controller (LCD), Air Conditioner Control Module, Electronic Chromic Mirror, Low Voltage DC-DC converter

BDC (Body Domain Controller), Multifunction Front View Camera, Crash Pad Switch, Intergrated Parking Assist Unit, Front Corner Radar LH/RH, Clutch Module Cylinder Sensor, AWD (4-Wheel Drive) ECU (Electronic Control Unit), Head Lamp LH/RH, Rear Corner Radar LH/RH

SCU (System Control Unit), Electronic Auto Transmission Shift Lever Switch

Instrument Cluster

Stop Lamp Switch, Overhead Console Lamp

Motor Driven Power Steering Unit

Burglar Alarm Horn Relay, Transaxle Range Switch, Power train Control Module, BDC (Body Domain Controller), Ignition Switch, E/R Junction Block (Start Relay)

CONSOLE UPPER EXTN(Shift By Wire), SCU

A/CON UNIT, HAZARD Switch, ICC UNIT

POWER WINDOW MAIN Switch, O/S MIRROR DRV/PASS

TRAILER (CTM2)

Active Air Flap (LOWER), VESS UNIT

DCU

TRAILER (E-BRAKE)

P-LBM, Front Heated Relay (Coil)

BDC

BMS(HEV/PHEV)

CCU

Battery Sensor (PHEV Only)

IGNITION Switch, BDC, BLE UNIT, UWB(FL/FR/RL/RR)

4WD ECU

Rain Sensor, KEY Soleniod (non SMK), OBD

OBC SIG (B+)

CCNC KEYBOARD, CONSOLE TRAY EXTN(Wireless Charger)

CCNC

ICC UNIT, POWER WINDOW MAIN Switch

SEAT EXTN DRV/PASS, CONSOLE TRAY EXTN, CONSOLE POWER OUTLET

CCU, Charge Door Module(PHEV only)

CCNC(PHEV), A/CON UNIT(PHEV), HEV COMP SIG

OBC SIG (IG3)
