• Once you set the ignition switch or ENGINE START/STOP Button to the ON position.

  • It appears for approximately 3 seconds and then goes off.

• When there is a malfunction with the ESC system.

  In this case, have the vehicle inspected by an authorized Kia dealer.

While the ESC is operating.

* For more details, refer to More Details.

• Once you set the ignition switch or ENGINE START/STOP Button to the ON position.

  • It appears for approximately 3 seconds and then goes off.

• When you deactivate the ESC system by pressing the ESC OFF button.

* For more details, refer to More Details.

• White When you activate the auto hold system by pressing the AUTO HOLD button.

• Green When you stop the vehicle completely by depressing the brake pedal with the auto hold system activated.

• Yellow When there is a malfunction with the auto hold system. In this case, have the vehicle inspected by an authorized Kia dealer.

* For more details, refer to More Details.

• When the vehicle detects the immobilizer in your key properly while the ignition switch is ON.

  • At this time, you can start the engine.

  • The indicator light goes off after starting the engine.

• When there is a malfunction with the immobilizer system.

  In this case, have the vehicle inspected by an authorized Kia dealer.

• When the vehicle detects the smart key in the vehicle properly while the ENGINE START/STOP button is ACC or ON.

  • At this time, you can start the engine.

  • The indicator light goes off after starting the engine.

• When the smart key is not in the vehicle.

  • At this time, you can not start the engine.

• When the vehicle can not detect the smart key which is in the vehicle while the ENGINE START/STOP Button is ON.

  In this case, have the vehicle inspected by an authorized Kia dealer.

• When the battery of the smart key is weak.

  • At this time, you can not start the engine. However, you can start the engine if you press the ENGINE START/STOP Button with the smart key. (For more details, refer to More Details).

• When there is a malfunction with the immobilizer system.

  In this case, have the vehicle inspected by an authorized Kia dealer.

• When you turn the turn signal light on.

If any of the following occurs, there may be a malfunction with the turn signal system. In this case, have the vehicle inspected by an authorized Kia dealer.

• The indicator light does not blink but appears.

• The indicator light blinks more rapidly.

• The indicator light does not appear at all.

• When the headlamps are on.

• When the headlamps are on and in the high beam position.

• When the turn signal lever is pulled into the Flash-to-Pass position.

• When the high beam is on with the light switch in the AUTO light position.

• If your vehicle detects oncoming or preceding vehicles, High Beam Assist will switch the high beam to low beam automatically.

* For more details, refer to More Details.

• When the taillamps or headlamps are on.

• When the front fog lights are on.

• Once you set the ignition switch or ENGINE START/STOP Button to the ON position.

  • The yellow indicator light illuminates for approximately 3 seconds and then goes off.

• Green When Lane Keeping Assist operating conditions are satisfied.

• Gray When Lane Keeping Assist operating conditions are not satisfied.

• Yellow When Lane Safety is deselected or disable/malfunction. In this case, have the vehicle inspected by an authorized Kia dealer.

• Green When Lane Keeping Assist is operating.

• When the cruise control system is enabled.

* For more details, refer to More Details.

When the vehicle is ready to be driven.

• ON: Normal driving is possible.

• OFF: Normal driving is not possible, or a problem has occurRred.

When the vehicle is driven by the electric motor.

• "EV" indicator ON: Vehicle is driven using the electric motor or the gasoline engine is stopped.

• "EV" indicator OFF: Vehicle is driven using the gasoline engine.

• When you select "SPORT" mode as drive mode.

For more details, refer to More Details.

• When you select "ECO" mode as drive mode.

For more details, refer to More Details.
