Exterior overview

Figure 1. Front view (Except CUV)
OCD011001

The actual shape may differ from the illustration.

  1. Hood Hood

  2. Head lamp Lighting, Light bulb position (Front)

  3. Wheel and tire Tires and wheels, Tires and wheels (5 Door, Wagon, Shooting brake)

  4. Outside rear view mirror Outside rear view mirror

  5. Panorama sunroof Panorama sunroof

  6. Front windshield wiper blades Wipers and washers, Wiper blades

  7. Windows Windows

  8. Front ultrasonic sensors Forward/Reverse Parking Distance Warning (PDW)

  9. Daytime running lamp or Front fog lamp Front fog light, Light bulb position (Front)

Figure 2. Front view (For CUV)
OCD012005L

The actual shape may differ from the illustration.

  1. Hood Hood

  2. Head lamp Lighting, Light bulb position (Front)

  3. Wheel and tire Tires and wheels, Tires and wheels (CUV)

  4. Outside rear view mirror Outside rear view mirror

  5. Panorama sunroof Panorama sunroof

  6. Front windshield wiper blades Wipers and washers, Wiper blades

  7. Windows Windows

  8. Front ultrasonic sensors Forward/Reverse Parking Distance Warning (PDW)

  9. Front fog lamp Front fog light, Front fog lamp bulb (Bulb type) replacement

Figure 3. Rear view (5 Door)
OCD011002

The actual shape may differ from the illustration.

  1. Door locks Door locks

  2. Fuel filler door Fuel filler door

  3. Rear combination lamp Light bulb position (Rear)

  4. High Mounted Stop Lamp Light bulb position (Rear)

  5. Tailgate Tailgate

  6. Antenna Antenna

  7. Wide-rear view camera Rear View Monitor (RVM)

  8. Rear ultrasonic sensors Reverse Parking Distance Warning (PDW), Forward/Reverse Parking Distance Warning (PDW)

Figure 4. Rear view (Wagon)
OCD011006

The actual shape may differ from the illustration.

  1. Door locks Door locks

  2. Fuel filler door Fuel filler door

  3. Rear combination lamp Light bulb position (Rear)

  4. High Mounted Stop Lamp Light bulb position (Rear)

  5. Tailgate Tailgate

  6. Antenna Antenna

  7. Wide-rear view camera Rear View Monitor (RVM)

  8. Rear ultrasonic sensors Reverse Parking Distance Warning (PDW), Forward/Reverse Parking Distance Warning (PDW)

  9. Back up lamp Light bulb position (Rear)

Figure 5. Rear view (Shooting Brake)
OCD011007

The actual shape may differ from the illustration.

  1. Door locks Door locks

  2. Fuel filler door Fuel filler door

  3. Rear combination lamp Light bulb position (Rear)

  4. High Mounted Stop Lamp Light bulb position (Rear)

  5. Tailgate Tailgate

  6. Antenna Antenna

  7. Wide-rear view camera Rear View Monitor (RVM)

  8. Rear ultrasonic sensors Reverse Parking Distance Warning (PDW), Forward/Reverse Parking Distance Warning (PDW)

Figure 6. Rear view (CUV)
OCD012008L

The actual shape may differ from the illustration.

  1. Door locks Door locks

  2. Fuel filler door Fuel filler door

  3. Rear combination lamp Light bulb position (Rear)

  4. High Mounted Stop Lamp Light bulb position (Rear)

  5. Tailgate Tailgate

  6. Antenna Antenna

  7. Wide-rear camera Rear View Monitor (RVM)

  8. Rear ultrasonic sensors Reverse Parking Distance Warning (PDW), Forward/Reverse Parking Distance Warning (PDW)

  9. Rear fog lamp Rear fog light, Light bulb position (Rear)

  10. Back up lamp Light bulb position (Rear)
