Vehicle load limit

The tire and loading information label on the driver side door displays your vehicle’s load limit.

Tire and loading information label

The label located on the driver side door sill lists the original tire size, the cold tire pressures recommended for your vehicle, the number of people that can be in your vehicle, and the vehicle capacity weight.

Figure 1. Example for label
OSVM096025N
Vehicle capacity weight:

  • 860 lbs. (380kg)

Vehicle capacity weight is the maximum combined weight of occupants and cargo. If your vehicle is equipped with a trailer, the combined weight includes the tongue load.

Seating capacity total: 5 persons (Front seat: 2 persons, Rear seat: 3 persons).

Seating capacity is the maximum number of occupants, including the driver, that your vehicle may carry.

The seating capacity may be reduced based on the weight of all the occupants and the weight of the cargo you are carrying or towing.

Do not overload your vehicle, as it has a load limit (or limit to the total weight, including occupants and cargo, that your vehicle can carry).

Towing capacity:

  • With brake system (2WD): 1,500 lbs. (680 kg)

  • With brake system (AWD, GT): 2,000 lbs. (907 kg)

Cargo capacity:

The cargo capacity of your vehicle increases or decreases depending on the weight, number of occupants, and the tongue load (if towing a trailer).
