Jack label

Figure 1. Type A
2026 Kia Tasman Jack label Type A image. Features icons and yellow car diagrams showing the model name (1), max load (2), and lifting points (6). It warns to use the jack on firm level ground (9). Describes safety precautions for using the jack.
N_TK25F018_E
Figure 2. Type B
2026 Kia Tasman jack label image. The label lists safety instructions such as 'TURN OFF IGNITION & SET PARKING BRAKE' and 'THE JACK SHOULD BE USED ON LEVEL FIRM GROUND'. A red warning box at the bottom reads 'WARNING: DO NOT GET UNDER A VEHICLE THAT IS SUPPORTED BY A JACK'. Explains the safety precautions and prohibitions when using the jack.
N_TK25F027_E

The actual jack label in the vehicle may differ from the illustration. For more detailed specifications, refer to the label attached to the jack.

  1. Model Name

  2. Maximum allowable load

  3. When using the jack, set your parking brake.

  4. When using the jack, stop the engine.

  5. Do not get under a vehicle that is supported by a jack.

  6. The designated locations under the frame

  7. When supporting the vehicle, the baseplate of jack must be vertical under the lifting point.

  8. Shift to P (Park) position on vehicles. If equipped with manual transmission, shift to R (Reverse) on vehicles.

  9. The jack should be used on firm level ground.

  10. Jack manufacturer

  11. Representative company and address
