• When the START/STOP button is in the ON position.

  • It appears for approximately 3 seconds and then goes off.

• When there is a malfunction with the ESC system.

  In this case, have the vehicle inspected by a professional workshop. Kia recommends to visit an authorized Kia dealer/service partner.

While the ESC is operating.

* For more details, refer to More Details.

• When the START/STOP button is in the ON position.

  • It appears for approximately 3 seconds and then goes off.

• When you deactivate the ESC system by pressing the ESC OFF button.

* For more details, refer to More Details.

When the vehicle detects the smart key in the vehicle with the START/STOP button in the ACC or ON position.

• Once the smart key is detected, you can start the vehicle ( indicator ON).

• The indicator light goes off after starting the vehicle ( indicator ON).

• When the smart key is not in the vehicle.

  • At this time, you can not start the vehicle.

• If the smart key is in the vehicle and the START/STOP button is ON, but the vehicle cannot detect the smart key.

  In this case, have your vehicle inspected by a professional workshop. Kia recommends to contact an authorized Kia dealer/service partner.

• When the battery of the smart key is weak.

• When there is a malfunction with the immobilizer system.

  In this case , have your vehicle inspected by a professional workshop. Kia recommends to contact an authorized Kia dealer/service partner.

• When you turn the turn signal light on.

If any of the following occurs, there may a malfunction with the turn signal system.

In this case, have the vehicle inspected by a professional workshop. Kia recommends to visit an authorized Kia dealer/service partner.

• The indicator light does not blink but appears.

• The indicator light blinks more rapidly.

• The indicator light does not appear at all.

• When the headlights are on.

• When the headlights are on and in the high beam position.

• When the turn signal lever is pulled into the Flash-to-Pass position.

• When the high-Beam is on with the light switch in the AUTO light position.

• If your vehicle detects oncoming or preceding vehicles, High Beam Assist will switch the high beam to low beam automatically.

* For more details, refer to More Details.

• When the tail lights or headlights are on.

• When the front fog lights are on.

• When the rear fog lights are on.

• When the vehicle is ready to be driven.

  • ON: Normal driving is possible.

  • OFF: Normal driving is not possible, or a problem has occurred.

  • Blinking: Emergency driving.

When the ready indicator goes OFF or blinks, there is a problem with the system. In this case, have the vehicle inspected by a professional workshop. Kia recommends to visit an authorized Kia dealer/service partner.

• When Cruise Control is enabled.

• When you select "SPORT" mode as drive mode.

• When you select "ECO" mode as drive mode.

• When you select "ECO+" mode as drive mode.
