Air bag inflation conditions

The actual air bags in the vehicle may differ from the illustration.

air bag inflation conditions

2026 Kia Tasman frontal collision air bag inflation condition image. A white pickup truck collides with the side of a grey SUV, with an explosion graphic at the front bumper indicating the impact point. Explains the conditions where front air bags are designed to inflate during a frontal collision.
N_TK25B071

Front air bags are designed to inflate in afrontal collision depending on the intensity, speed or angles of impact of the front collision.

2026 Kia Tasman side collision scenario image. A grey SUV is shown crashing into the side of the white pickup truck at an intersection, with an explosion graphic indicating the point of impact. Explains the conditions where side and curtain air bags are designed to inflate when a side impact is detected.
N_TK25B070

Side and/or curtain air bags are designed to inflate when an impact is detected by side collision sensors depending on the strength, speedor angles of impact resulting from a side impact collision

NOTE
  • Side and curtain air bags

    The side and curtain air bags are designed to inflate when a rollover is detected by a rollover sensor.

    Although the front air bags (driver's and front passenger's air bags) are designed to inflate only in frontal collisions, they also may inflate in other types of collisions if the front impact sensors detect a sufficient impact. Side air bags (side and/or curtain air bags) are designed to inflate only in side impact collisions, but they may inflate in other collisions if the side impact sensors detect a sufficient impact.

    For instance, side air bag and curtain air bags may inflate if rollover sensors indicate the possibility of a rollover occurring (even if none actually occurs) or in other situations, including when the vehicle is tilted while being towed. Even if side and/or curtain air bags do not provide impact protection in a rollover, they will deploy to prevent ejection of occupants, especially those who are restrained with seat belts.

    If the vehicle chassis is impacted by bumps or objects on unimproved roads or sidewalks, air bags may deploy. Drive carefully on unimproved roads or on surfaces not designed for vehicle traffic to prevent unintended air bag deployment.

NOTE

If equipped with rollover sensor

Also, the side and curtain air bags are designed to inflate when a rollover is detected by a rollover sensor.
