Indicator lights
Electronic stability control (ESC) indicator light
-
Once you set the ignition switch or ENGINE START/STOP Button to the ON position.
-
It illuminates for approximately 3 seconds and then goes off.
-
-
When there is a malfunction with the ESC system.
In this case, have the vehicle inspected by an authorized Kia dealer.
Electronic stability control (ESC) OFF indicator light
-
Once you set the ignition switch or ENGINE START/STOP Button to the ON position.
-
It illuminates for approximately 3 seconds and then goes off.
-
-
When you deactivate the ESC system by pressing the ESC OFF button.
* For more details, refer to More Details.
AUTO HOLD indicator light (AUTO HOLD)
-
White When you activate the auto hold system by pressing the AUTO HOLD button.
-
Green When you stop the vehicle completely by depressing the brake pedal with the auto hold system activated.
-
Yellow When there is a malfunction with the auto hold system. In this case, have the vehicle inspected by an authorized Kia dealer.
* For more details, refer to More Details.
Immobilizer indicator light (without smart key)
(if equipped)
-
When the vehicle detects the immobilizer in your key properly while the ignition switch is ON.
-
At this time, you can start the engine.
-
The indicator light goes off after starting the engine.
-
-
When there is a malfunction with the immobilizer system.
In this case, have the vehicle inspected by an authorized Kia dealer.
Immobilizer indicator light (with smart key)
-
When the vehicle detects the smart key in the vehicle properly while the ENGINE START/STOP button is ACC or ON.
-
At this time, you can start the engine.
-
The indicator light goes off after starting the engine.
-
-
When the smart key is not in the vehicle.
-
At this time, you can not start the engine.
-
-
When the vehicle can not detect the smart key which is in the vehicle while the ENGINE START/STOP Button is ON.
In this case, have the vehicle inspected by an authorized Kia dealer.
-
When the battery of the smart key is weak.
-
At this time, you can not start the engine. However, you can start the engine if you press the ENGINE START/STOP Button with the smart key. (For more details, refer to More Details).
-
-
When there is a malfunction with the immobilizer system.
In this case, have the vehicle inspected by an authorized Kia dealer.
Turn signal indicator light
-
When you turn the turn signal light on.
If any of the following occurs, there may a malfunction with the turn signal system. In this case, have the vehicle inspected by an authorized Kia dealer.
-
The indicator light does not blink but illuminates.
-
The indicator light blinks more rapidly.
-
The indicator light does not illuminate at all.
Low beam indicator light
-
When the headlamps are on.
High beam indicator light
-
When the headlamps are on and in the high beam position.
-
When the turn signal lever is pulled into the Flash-to-Pass position.
High Beam Assist indicator light
-
When the high beam is on with the light switch in the AUTO light position.
-
If your vehicle detects oncoming or preceding vehicles, High Beam Assist will switch the high beam to low beam automatically.
* For more details, refer to More Details.
Light ON indicator light
-
When the taillamps or headlamps are on.
Front fog indicator light
(if equipped)
-
When the front fog lights are on.
Lane Safety indicator light
Lane Safety indicator light will illuminate when you turn Lane Keeping Assist on by pressing Lane Safety button.
If there is a problem with the system, the yellow Lane Safety indicator light will illuminate.
* For more details, refer to More Details.
Cruise Control indicator light
(if equipped)
-
When the cruise control system is enabled.
* For more details, refer to More Details.
SPORT Mode indicator light
-
When you select "SPORT" mode as drive mode.
For more details, refer to More Details.
ECO Mode indicator light
-
When you select "ECO" mode as drive mode.
For more details, refer to More Details.
