Mode selection

The mode selection button controls the direction of airflow through the ventilation system.

N_SP3i26_C08_010_I

Face-Level (2, 4, 6)

Air flow is directed toward the upper body and face. You can control the direction of the airflow from each vent.

Bi-Level (2, 3, 4, 5, 6)

Air flow is directed toward the upper body and face and the floor.

Floor-Level (1, 3, 4, 5)

Most of the airflow is directed to the floor, and a small amount is directed to the windshield, side window defrosters, and side air vents.

Floor/Defrost-Level (1, 3, 4, 5)

Most of the airflow is directed to the floor and windshield, and a small amount is directed to the side window defrosters and side air vents.

Defrost-Level (1, 4)

Most of the air flow is directed to the windshield, and a small amount is directed to the side window defrosters and side air vents.

Instrument panel vents

Figure 1. Front
N_SP327_C08_008_1
Figure 2. Center (if equipped)
N_SP327_C08_009

You can adjust the direction of a vent’s airflow using the vent control lever as shown.

The vent’s airflow stops when you move the air vent control lever to the closed position ( ).

Air flows through the vent when you move the air vent control lever to the open position ( ).
