Recommended lubricants and capacities
To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality.
The correct lubricants also help promote engine efficiency that results in improved fuel economy.
These lubricants and fluids are recommended for use in your vehicle.
|
Lubricant |
Volume |
Classification |
||
|---|---|---|---|---|
|
Engine oil *1 *2 (drain and refill) Recommends |
Smartstream G2.5 FR T-GDi |
2WD: 6.4 L (6.76 US qt.) 4WD: 6.0 L (6.34 US qt.) |
Full synthetic SAE 0W-30, API SN PLUS/SP or ILSAC GF-6*3 |
|
|
(Gasoline) 3.3 T-GDi |
6.9 L (7.29 US qt.) |
Full synthetic SAE 5W-30 ACEA A5/B5*3 |
||
|
Automatic transmission fluid |
Smartstream G2.5 FR T-GDi |
9.2 L (9.72 US qt.) |
GS ATF SP-IV-RR KIA genuine ATF SP-IV-RR |
|
|
(Gasoline) 3.3 T-GDi |
||||
|
Coolant |
Smartstream G2.5 FR T-GDi |
Engine coolant |
9.5 L (10.03 US qt.) |
Mixture of antifreeze and distilled water (Ethylene glycol base coolant for aluminum radiator) |
|
Water cooled type Inter cooler |
2.7 L (2.85 US qt.) |
|||
|
Gasoline) 3.3 T-GDi |
11.6 L (12.25 US qt.) |
|||
|
Brake fluid*4 |
0.395 L (0.42 US qt.) |
SAE J1704 DOT-4LV, ISO4925 CLASS-6, FMVSS116 DOT-4 |
||
|
Rear differential oil (without LSD)*5 |
Smartstream G2.5 FR T-GDi |
1.2 L (1.27 US qt.) |
HYPOID GEAR OIL API GL-5 SAE 75W/85 (SK HK SYN GEAR OIL 75W85) |
|
|
(Gasoline) 3.3 T-GDi |
1.3 L (1.37 US qt.) |
|||
|
Rear differential oil (with LSD) *5*6 |
Smartstream G2.5 FR T-GDi |
1.3 L (1.37 US qt.) |
HYPOID GEAR OIL API GL-5 SAE 75W/85 (SK HK JL SYN LSD GEAR OIL 75W85 FM PLUS or equivalent ) |
|
|
(Gasoline) 3.3 T-GDi |
1.4 L (1.48 US qt.) |
|||
|
Front differential oil (AWD)*5 |
0.7 L (0.74 US qt.) |
HYPOID GEAR OIL API GL-5 SAE 75W/85 (SK HK SYN GEAR OIL 75W85) |
||
|
Transfer oil (AWD) |
Gear/ Clutch |
0.57 L (0.60 US qt.) |
SHELL TF 0870B |
|
|
Actuator |
0.25 L (0.26 US qt.) |
|||
|
Fuel |
60 L (15 US gal.) |
Refer to More Details. |
||
* 1. Refer to the recommended SAE viscosity numbers on the next page.
* 2. Engine oils labeled Energy Conserving Oil are now available. Along with other additional benefits, they contribute to fuel economy by reducing the amount of fuel necessary to overcome engine friction. Often, these improvements are difficult to measure in everyday driving, but in a year’s time, they can offer significant cost and energy savings.
* 3. Requires <API SN PLUS/SP(ILSAC Latest) Full synthetic> grade engine oil for 2.5 FR T-GDI and <API Latest(ILSAC Latest) or ACEA A5/B5 Full synthetic> grade engine oil for 3.3 T-GDI. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated severe maintenance condition.
* 4. To maintain your vehicle’s best brake and ABS/ESC performance, use Kia genuine brake fluid as in the specification.
* 5. Regardless of oil change intervals, replace oil immediately if Rear-Differential or Front-Differential is submerged.
* 6. Be sure to inject oil for exclusive use of LSD when replacing Rear Differential (for LSD) Oil.
Recommended SAE viscosity number
Engine oil viscosity (thickness) has an effect on fuel economy and cold weather operating (engine start and engine oil flowability). Lower viscosity engine oils can provide better fuel economy and cold weather performance; however, higher viscosity engine oils are required for satisfactory lubrication in hot weather. Using oils of any viscosity other than those recommended could result in engine damage. When choosing an oil, consider the range of temperature your vehicle will be operated in before the next oil change. Proceed to select the recommended oil viscosity from the chart.
|
Temperature Range for SAE Viscosity Numbers |
|||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Temperature |
°C |
-30 |
-20 |
-10 |
0 |
10 |
20 |
30 |
40 |
50 |
|||||||||||||||||||||||||
|
°F |
-10 |
0 |
20 |
40 |
60 |
80 |
100 |
120 |
|||||||||||||||||||||||||||
|
Gasoline Engine Oil |
Smartstream G2.5 FR T-GDi*1 |
0W-30 |
|||||||||||||||||||||||||||||||||
|
(Gasoline) 3.3 T-GDi*2 |
10W-30 |
||||||||||||||||||||||||||||||||||
|
5W-30 |
|||||||||||||||||||||||||||||||||||
* 1 : For better fuel economy, it is recommended to use the engine oil of a viscosity grade SAE 0W-30 (ACEA C2 or above). However, if the engine oil is not available in your country, select the proper engine oil using the engine oil viscosity chart.
* 2 : For better fuel economy, it is recommended to use the engine Oil of a viscosity grade SAE 5W-30 (ACEA A5/B5 or API Latest (or ILSAC Latest)). However, if the engine oil is not available in your country, select the proper engine oil using the engine oil viscosity chart.
.png)
An engine oil displaying this API Certification Mark conforms to the international Lubricant Specification Advisory Committee (ILSAC). It is recommended to only use engine oils that uphold this API Certification Mark.
