Instrument cluster

Figure 1. Type A
OLQ2AH005030
Figure 2. Type B
OLQ2AH005031

The actual instrument cluster in the vehicle may differ from the illustrations.

  1. Warning and indicator lights

  2. Speedometer

  3. Tachometer/Power gauge

  4. Distance to empty

  5. Fuel gauge

  6. Outside temperature gauge

  7. Transmission shift indicator

  8. Hybrid battery SOC gauge

  9. Odometer
