This warning light illuminates:

• Once you set the ENGINE START/STOP button to the ON position.

  • It illuminates for approximately 6 seconds and then goes off.

• When there is a malfunction with the SRS.

  In this case, have the vehicle inspected by an authorized Kia dealer.

* For more details, refer to More Details.

• Once you set the ENGINE START/STOP button to the ON position.

  • It illuminates for approximately 3 seconds

  • It remains on if the parking brake is applied.

• When the parking brake is applied.

• When the brake fluid level in the reservoir is low.

  • If the warning light illuminates with the parking brake released, it indicates the brake fluid level in reservoir is low.

1. Drive carefully to the nearest safe location and stop your vehicle.

2. With the engine stopped, check the brake fluid level immediately and add fluid as required (For more details, refer to More Details). Then check all brake components for fluid leaks. If any leak on the brake system is still found, the warning light remains on, or the brakes do not operate properly, do not drive the vehicle.

   In this case, we recommend that the vehicle be towed to an authorized Kia dealer and inspected.

Your vehicle is equipped with dual-diagonal braking systems. This means you still have braking on two wheels even if one of the dual systems should fail.

With only one of the dual systems working, more than normal pedal travel and greater pedal pressure are required to stop the vehicle.

Also, the vehicle will not stop in as short a distance with only a portion of the brake system working.

If the brakes fail while you are driving, shift to a lower gear for additional engine braking and stop the vehicle as soon as it is safe to do so.

WARNING

Parking Brake & Brake Fluid Warning Light

Driving the vehicle with a warning light ON is dangerous. If the Parking Brake & Brake Fluid Warning Light illuminates with the parking brake released, it indicates that the brake fluid level is low.

In this case, we recommend that the vehicle be inspected by an authorized Kia dealer.

• Once you set the ENGINE START/STOP button to the ON position.

  • It illuminates for approximately 3 seconds and then goes off.

• When there is a malfunction with the ABS (The normal braking system will still be operational without the assistance of the anti-lock brake system).

  In this case, have the vehicle inspected by an authorized Kia dealer.

• When the ABS and regular brake system are not working, we recommend that the vehicle be inspected by an authorized Kia dealer.

WARNING

Electronic Brake Force Distribution (EBD) System Warning Light

When both ABS and Parking Brake & Brake Fluid Warning Lights are on, the brake system will not work normally and you may experience an unexpected and dangerous situation during sudden braking.

In this case, avoid high speed driving and abrupt braking.

we recommend that the vehicle be inspected by an authorized Kia dealer as soon as possible.

• Once you set the ENGINE START/STOP button to the ON position.

  • This indicator light comes on after the ENGINE START/STOP button is turned to the ON position and then goes out after approximately 3 seconds.

• When there is a malfunction with the EPS.

  In this case, have the vehicle inspected by an authorized Kia dealer.

• Once you set the ENGINE START/STOP button to the ON position.

• When there is a malfunction with either the alternator or electrical charging system.

1. Drive carefully to the nearest safe location and stop your vehicle.

2. Turn the engine off and check the alternator drive belt for looseness or breakage.

   In this case, have the vehicle inspected by an authorized Kia dealer.

• Once you set the ENGINE START/STOP button to the ON position.

  • It illuminates for approximately 3 seconds and then goes off.

• When FCA is turned off.

• When the radar sensor or cover is blocked with dirt or snow. Check the sensor and cover and clean them by using a soft cloth.

• When there is a malfunction with FCA. If this occurs, we recommend that the vehicle be inspected by an authorized Kia dealer.

* For more details, refer to More Details and More Details.

• Once you set the ENGINE START/STOP button to the ON position.

  • It illuminates for approximately 3 seconds and then goes off.

• When there is a malfunction with the EPB.

  In this case, have the vehicle inspected by an authorized Kia dealer.

NOTICE

Electronic Parking Brake (EPB) Warning Light

The Electronic Parking Brake (EPB) Warning Light may illuminate when the Electronic Stability Control (ESC) Indicator Light comes on to indicate that the ESC is not working properly (This does not indicate malfunction of the EPB).

• When accumulated soot reaches a certain amount.

• When this warning light illuminates, it may turn off after driving the vehicle:

  • The vehicle should be driven for more than 30 minutes at a speed of 80 km/h and faster.

  • Ensure the following conditions are all met: safe road conditions, transmission 3rd gear or above, and engine speed of 1,500~4,000 rpm.

If this warning light blinks in spite of the procedure (at this time the LCD warning message will be displayed), have the GPF system checked by a professional workshop. We recommend that you contact an authorized Kia dealer.

CAUTION

Gasoline Engine with GPF (if equipped)

If you continue to drive with the GPF warning light blinking for a long time, the GPF system can be damaged and fuel consumption can worsen.

• When you set the ENGINE START/STOP button to the ON position.

  • The malfunction indicator light illuminates for about 3 seconds and then goes off.

• Whenever there is a malfunction with either the emission control system or the engine or the vehicle powertrain.

  In this case, have the vehicle inspected by an authorized Kia dealer.

CAUTION

Malfunction Indicator Lamp (MIL)

Driving with the Malfunction Indicator Lamp (MIL) on may cause damage to the emission control systems which could effect drivability and/or fuel economy.

If the oil pressure lowers due to insufficient engine oil, etc., the engine oil pressure warning light turns on and an enhanced engine protection system that limits the engine's power is activated. After that, engine warning light turns on if driving repeatedly and continuously.

CAUTION

If the Malfunction Indicator Lamp (MIL) illuminates, potential catalytic converter damage is possible which could result in loss of engine power. In this case, have the vehicle inspected by an authorized Kia dealer.

• Once you set the ENGINE START/STOP button to the ON position.

  • It remains on until the engine is started.

• When the engine oil pressure is low.

• If the oil pressure lowers due to insufficient engine oil, etc., the engine oil pressure warning light turns on and an enhanced engine protection system that limits the engine's power is activated.

• If this warning light turns on while driving, drive carefully to the side of the road and stop the vehicle, check the engine oil level (For more details, refer to More Details) and add if insufficient.

• If the engine oil isn't insufficient, or if the warning light does not turn off even after adding, have the vehicle inspected by an authorized Kia dealer. Driving with the warning light on may cause engine failure.

  * When oil pressure is restored to an optimal level, the oil pressure warning light and the protection system that limits engine power will turn off. Even if the oil pressure returns to normal, check the engine once again in a safe place.

CAUTION

Engine Overheating

Do not continue driving with the engine overheated. Otherwise, the engine may be damaged.

CAUTION

Engine damage

If the engine is not stopped immediately after the engine oil pressure warning light is illuminated and stays on while the engine is running, serious engine damage may result.

CAUTION

Engine Oil Pressure Warning Light

• If the warning light stays on while the engine is running, it indicates that there may be serious engine damage or malfunction. In this case,

  1. Stop the vehicle as soon as it is safe to do so.

  2. Turn off the engine and check the oil level. If the oil level is low, fill the engine oil to the proper level.

  3. Start the engine again. If the warning light stays on after the engine is started, turn the engine off immediately. In this case, have the vehicle inspected by an authorized Kia dealer.

When the fuel tank is nearly empty.

Add fuel as soon as possible.

CAUTION

Low Fuel Level

Driving with the Low Fuel Level warning light on or with the fuel level below "E" can cause the engine to misfire and damage the catalytic converter.

• This warning light informs the driver the following situations

  • LED headlamp malfunction

  • Lamp malfunction

  • High Beam Assist malfunction (if equipped)

To identify the details of the warning look at the LCD display.

If the warning situation is solved, the master warning light will turn off.

• Once you set the ENGINE START/STOP button to the ON position.

  • It illuminates for approximately 3 seconds and then goes off.

• When one or more of your tires are significantly under inflated. (The location of the underinflated tires are displayed on the LCD display).

* For more details, refer to More Details.

• When there is a malfunction with the TPMS.

  In this case, we recommend that the vehicle be inspected by an authorized Kia dealer.

* For more details, refer to More Details.

WARNING

Low tire pressure

• Significantly low tire pressure makes the vehicle unstable and can contribute to loss of vehicle control and increased braking distances.

• Continued driving or low pressure tires will cause the tires to overheat and fail.

WARNING

Safe Stopping

• The TPMS cannot alert you to severe and sudden tire damage caused by external factors.

• If you notice any vehicle instability, immediately take your foot off the accelerator pedal, apply the brakes gradually with light force, and slowly move to a safe position off the road.

• Once you set the ENGINE START/STOP button to the ON position.

  • It illuminates for approximately 3 seconds and then goes off.

• When there is a malfunction with the LED headlamp.

In this case, we recommend that the vehicle be inspected by an authorized Kia dealer.

• When there is a malfunction with a LED headlamp related part.

In this case, we recommend that the vehicle be inspected by an authorized Kia dealer.
