Hybrid battery cooling duct (Hybrid vehicle)

Figure 1. Inlet duct
OLQ2AH075001

The hybrid battery cooling duct is located below the right side of the front seats. The cooling duct cools down the hybrid battery. When the hybrid battery cooling duct is blocked, the hybrid battery might overheat.

Clean the cooling duct for the hybrid battery with a dry cloth on a regular basis.

WARNING
  • Never clean the cooling duct of the hybrid battery with a wet cloth. If any water enters the cooling duct of the hybrid battery, the hybrid battery might cause an electric shock, resulting in a serious damage, injury, or death.

  • Lithium-ion composes the hybrid battery. The hybrid battery is dangerous to the environment if improperly handled. The hybrid battery might also cause electric shock and severe burns, resulting in serious injury or death.

  • Do not spill liquid on the cooling duct of the hybrid battery. Doing so is very dangerous, and might cause electric shock or serious injury.

  • Do not cover the cooling duct with objects.

  • Do not put any objects into the cooling duct of the hybrid battery. Doing so might cause loss of the cooling duct volume. If any objects block the cooling duct, immediately contact a Kia dealer.

  • Never place a container of liquid on or near the cooling duct. Spilled liquid might damage the hybrid battery.

  • Before driving, secure all luggage in the liftgate. When a sharp or heavy load strikes with a strong impact or pierces the liftgate’s interior wall, the hybrid battery system might be damaged, deteriorating its performance.

  • Do not obstruct the cooling duct with any other objects.
