Rear view monitor (if equipped)

You may check the rear view through the screen while driving.

The system is activated when:

  • The engine is ON

  • The vehicle’s speed is over 15 km/h and you press the SVM button (1, indicator ON)

  • The vehicle’s speed is under 15 km/h and you press the (2) on the screen

The system is deactivated when:

  • You press the SVM button (1, indicator OFF) again

  • You press the (2) on the screen again

  • You press the audio or multimedia screen system button (3)

NOTICE

  • If vehicle speed is over 15 km/h (9 mph)

    • the rear image stays ON when the rear view was on the screen

    • if other modes (top, front wide, front right and front left) of SVM system was on the screen, the screen changes to the screen of rear view.

  • If the SVM system is ON and the vehicle speed is under 15 km/h (9 mph)

    • the rear image stays ON when the rear view was on the screen

    • a pop-up for selecting the SVM mode (top, front wide, front right and front left) appears when pressing (2) on the screen

  • When the vehicle is backing up, the rear image will appear on the screen automatically regardless of the vehicle speed or SVM button (1) status.

    • If the rear image was ON, the screen switches to the parking assist screen.

    • If the screen (top, front wide, front right and front left) of other modes of SVM system was ON, the screen for setting the initial rear view mode appears.

    • When the shift lever is moved from R (Reverse) to D (Drive), the screen of the previous mode is displayed.

  • A warning appears on the SVM system when

    • the tailgate is opened

    • the driver/passenger’s door is opened

    • the outside rearview mirror is folded

WARNING

  • The Rear View Monitor system is a supplementary driving assist system. Make sure to check the rear view directly for safety.What you see on the screen may differ from the actual vehicle’s location.

  • If the camera lens is covered with foreign material, the Surround View Monitor may not operate normally.

    Always keep the camera lens clean.

    However, do not use chemical solvents such as strong detergents containing high alkaline or volatile organic solvents (gasoline, acetone etc.). This may damage the camera lens.

  • When the rear view is displayed while driving, an icon () is indicated on the upper right side of the screen.
