• Once you set the ignition switch to the ON position.

  • It appears for approximately 3 seconds and then goes off.

• When there is a malfunction with the ESC system.

  In this case, have the vehicle inspected by a professional workshop. Kia recommends to visit an authorized Kia dealer/service partner.

• While the ESC is operating.

* For more details, refer to More Details.

• Once you set the ignition switch to the ON position.

  • It appears for approximately 3 seconds and then goes off.

• When you deactivate the ESC system by pressing the ESC OFF button.

* For more details, refer to More Details.

• When the vehicle detects the immobilizer in your key properly while the ignition switch is ON.

  • At this time, you can start the engine.

  • The indicator light goes off after starting the engine.

• When there is a malfunction with the immobilizer system.

  In this case, have the vehicle inspected by a professional workshop. Kia recommends to visit an authorized Kia dealer/service partner.

• When you switch on the turn signal light on.

If any of the following occurs, there may a malfunction with the turn signal system. In this case, have the vehicle inspected by a professional workshop. Kia recommends to visit an authorized Kia dealer/service partner.

• The indicator light does not blink but illuminates.

• The indicator light blinks more rapidly.

• The indicator light does not illuminate at all.

• When the headlights are on and in the high beam position

• When the turn signal lever is pulled into the Flash-to-Pass position.

• When the tail lights or headlights are on.

• When the front fog lights are on.

• When the rear fog lights are on.

• When the engine is being preheated with the ignition switch in the ON position.

  • The engine can be started after the glow indicator light goes off.

  • The illumination time varies with the engine coolant temperature, air temperature, and battery condition.

If the indicator light remains on or blinks after the engine has warmed up or while driving, there may a malfunction with the engine preheating system.

In this case, have the vehicle inspected by a professional workshop. Kia recommends to visit an authorized Kia dealer/service partner.

NOTICE

Engine Preheating

If the engine does not start within 10 seconds after the preheating is completed, set the ignition switch to the LOCK or OFF position for 10 seconds and then to the ON position in order to preheat the engine again.

• When the key is turned to the ON position, the 4WD indicator light will come on and then go off in a few seconds.

• The 4WD indicator light will illuminate when the transfer shift lever is set to 4H or 4L position.

• When transferring to four-wheeldrive mode, have the lever positioned at the right position (2H, 4H, or 4L). In particular, if the lever is shifted from the 4H position into the 4L position with the lever positioned between the two points, The N (Neutral) indicator light will still illuminate but the drivetrain could fail to transfer power to the front and rear wheels. The driver must be on full alert as such failure could be highly dangerous.

• When the cruise control system is enabled.

* For more details, refer to More Details.

• When the cruise control speed is set.

* For more details, refer to More Details.
