Using the USB Devices

• Connect the USB device after turning on the engine. The USB device may become damaged if it is already connected when the ignition is turned on. The USB device may not operate properly if the car ignition is turned on or off with the USB device connected.

• Be careful for static electricity when connecting/disconnecting USB devices.

• Encoded MP3 Players will not be recognized when connected as an external device.

• When connecting an external USB device, the vehicle's Infotainment System may not recognize the USB depending on what firmware is used by USB device or what files are on the USB.

• Only products formatted with byte/sectors under 64Kbyte will be recognized.

• This device recognizes USB devices formatted in FAT 12/16/32 file formats. This device does not recognize files in NTFS file format.

• Some USB devices may not be supported due to compatibility issues.

• Avoid contact between the USB connector and bodily parts or foreign objects.

• Repeated connecting/disconnecting of USB devices within short periods of time may result in product malfunction.

• A strange noise may occur when disconnecting the USB.

• Make sure to connect/disconnect external USB devices with the audio power turned off.

• The amount of time required to recognize the USB device may differ depending on the type, size or file formats stored on the USB. Such differences in time are not indications of malfunctions.

• The vehicle Infotainment System only supports USB devices designed to play music files.

• USB images and videos are not supported.

• Do not use the USB I/F to charge batteries or USB accessories that generate heat. Doing so may lead to worsened performance or damage to the Infotainment System.

• The Infotainment System may not recognize the USB device if separately purchased USB hubs and extension cables are being used. Connect the USB device directly with the USB port of the vehicle.

• When using mass storage USB devices with separate logical drives, only files saved to the root drive can be played.

• Files may not properly operate if application programs are installed on the USBs.

• The Infotainment System may not operate normally if MP3 Players, cellular phones, digital cameras, or other electronic devices (USB devices not recognized as portable disk drives) are connected with the Infotainment System.

• Charging through the USB may not work for some mobile devices.

• The device may not support normal operation when using an atypical USB memory device (miniature, keychain, etc.). For best results, use a typical USB device that has a metal case.

• The device may not support normal operation when using formats such as HDD Type, CF, or SD Memory.

• The device will not support files locked by DRM (Digital Rights Management.).

• USB memory sticks used by connecting an Adaptor (SD Type or CF Type) may not be properly recognized.

• The device may not operate properly when using USB HDDs or USBs subject to connection failures caused by vehicle vibrations. (e.g. i-stick type)

•
  Avoid use of USB memory products that can also be used as key chains or mobile phone accessories. Use of such products may cause damage to the USB jack.

• Connecting an MP3 device or phone through various channels, such as AUX or Audio/USB mode may result in pop noises or abnormal operation.

Using an iPod®

• iPod® is a registered trademark of Apple Inc.

• In order to use the iPod® with your vehicle’s Infotainment System, you must use a dedicated iPod® cable. (the cable that is supplied when purchasing iPod®/iPhone® products)

• If the iPod® is connected to the vehicle while it is playing, a high pitch sound could occur for approximately 1-2 seconds immediately after connecting. If possible, connect the iPod® to the vehicle with the iPod® stopped/paused.

• When the vehicle ignition is set to ACC or ON, connecting the iPod® through the iPod® cable will charge the iPod® through the car Infotainment System.

• When connecting with the iPod® cable, make sure to fully insert the jack to prevent communication interference.

• When the EQ features of an external device, such as the iPod®, and the Infotainment System are both active, EQ effects could overlap and cause sound deterioration and distortion. Whenever possible, turn off the EQ feature within the external device when it is connected to the Infotainment System.

• Noise may occur when an iPod® or AUX device is connected. When such devices are not being used, disconnect the device for storage.

• When the iPod® or AUX device power is connected to the power jack, playing the external device may result in noise. In such cases, disconnect the power connection before use.

• Skipping or improper operation may occur depending on the characteristics of your iPod®/iPhone® device.

• If your iPhone® is connected to both the Bluetooth® Wireless Technology and USB, the sound may not be properly played. In your iPhone®, select the Dock connector or Bluetooth® Wireless Technology to change the sound output (source).

• iPod® mode cannot be operated when the iPod® cannot be recognized due to the playing of versions that do not support communication protocols, cases of iPod® abnormalities and defects.

• For fifth generation iPod® Nano devices, the iPod® may not be recognized when the battery level is low. Please charge the iPod® for use.

• The search/play orders shown within the iPod® device may differ from the orders shown within the Infotainment System.

• If the iPod® malfunctions due to an iPod® device defect, reset the iPod® and try again. (To learn more, refer to your iPod® manual)

• Some iPod®s may not sync with the System depending on the version. If the Media is removed before the Media is recognized, then the system may not properly restore the previously operated mode. (iPad® charging is not supported.)

• Use an iPod® cable shorter than 1 meter in length such as the one originally supplied with a new iPod®, longer cables may lead to the Infotainment System not recognizing the iPod®.

AUX don’t support Repeat, Random, SEEK and Rewind/Fast forward feature.

AUX and iPod® don’t support playlist feature.
